Extra Heavy Duty Arms

The models below are untooled like the EL-Series arms that end in “-N ” but with the addition of a Air Tool Supply hose . These can be used with custom holders for higher torque applications and air tools with higher weights up to 25+ lbs ! Consult with ETA or your distributor if you have an application for these Extra Heavy Duty Arms.

PA-Series arms are meant to be used with air tools. For any other type of tool; electric, battery, hydraulic, and fixtures or gauges, you should review the EL-Series arms. Our Air Cylinder gives you the smoothest float of any method and decades of life (more than 50,000,000 rundowns).

MODELDESCRIPTIONSPEC PDFMAX. VERT. TORQUE
in-lbs (Nm)
MAX. HORZ. TORQUE
in-lbs (Nm)
MAX. TOOL WEIGHT
lbs(Kg)
MAX. REACH
in. (mm)
STANDARD BASE INCLUDEDTOOL HOLDER INCLUDED
PA1015-N-B125Untooled Arm with thick Parallels and Cross Ties combined with larger diameter Shoulder Pin for more rigidity. This model has standard duty base and 3/8" ID tool supply hose.Download Specs1,100 (125)600 (68)14 (6.3)36" (915)12 inch (B125-12)NONE
PA1015-N-B250Same as PA1015-B125 above but with B250 Base Kit for extending the EL1015-N more than 12" from the mounting surface. B250-0 kit has Heavy Duty Base Plate with 2-1/2 npt threads and a 2-1/2 to 1-1/4 npt reducer. It is intended to make it convenient for customer to produce a robust mounting base simply by purchasing threaded pipe of the necessary lengths. See page 2 of SPEC PAGE for details.Download Specs1,100 (125)600 (68)14 (6.3)36" (915)0 inches (B250-0 Kit)NONE
PA1025-NUntooled arm with Extra Heavy Duty Parallel Rack like PA1015 but with our largest float cylinder and balance controls added for 25 lb (11.4 Kg) tooling weight capacity. 3/8" ID tool supply hose. B250-0 kit has Heavy Duty Base Plate with 2-1/2 npt threads and a 2-1/2 to 1-1/4 npt reducer. It is intended to make it convenient for customer to produce a robust mounting base simply by purchasing threaded pipe of the necessary lengths. See page 2 of SPEC PAGE for details.Download Specs1,100 (125)600 (68)25 (11.4)36" (915)0 inches (B250-0 Kit)NONE
